UL 94V0 RATED NI/CU NYLON RIPSTOP (NRS) FABRIC-OVER-FOAM

EcoTemp™ 85 X1G EMI gaskets provide excellent EMI shielding performance for customers where EMI issues occur. The gaskets are composed of electrically conductive fabric wrapped around a newly developed urethane foam core which will satisfy the requests for higher temperature resistance and lower compression set. They are supplied with either a conductive or non-conductive pressure sensitive adhesive (PSA), and can be equipped with an Extended Release Liner (ERL) on the adhesive. The gasket is a halogen-free, UL 94V0 rated product that can be created with cross-section profiles such as rectangle, D, C, P, T, knife, bell shapes, and others. The gaskets can be further customized to an application by die-cutting,

FEATURES

• Fabric-over-Foam gaskets are RoHS compliant

• Halogen-free per IEC-61249-2-21 standard

• UL 94V0

• Low surface resistivity of < 0.07 Ω/□provides excellent conductivity

• Shielding effectiveness of >80 dB acrossa wide spectrum of frequencies

• Fabric is highly conductive to provide goodEMI shielding and grounding

• Abrasion resistant metallized fabricsshow virtually no degradation in electricalperformance after 1,000,000 cycles

• Laird’s proprietary coatingprevents fabric fraying and fingerprinting

• Available with conductive ornon-conductive PSA

• Many cross-section profiles available such asrectangle, D, C, P, T, knife, bell and more

• Profile gaskets can be cut to specified lengths,kiss-cut on release liner, or mitered to formframe configurations

• Higher performance with lower compressionset values

MARKETS

• Cabinet applications

• LCD and Plasma TV

• Medical equipment

• Servers

• Printers

• Laptop computers

• Networking equipment

• Desktop computers

• Telecommunications cabinets
