HIGH PERFORMANCE THERMAL INTERFACE PRODUCTS

Tgard™ 300 is a medium thermal performance insulator pad consisting of a ceramic high temperature silcone rubber coated on electrical fiberglass.

Tgard 300 is specifically designed for applications that require low component mounting forces. The unique formulation will enhance thermal performance which minimizes thermal resistance at low mounting forces. The uniqe coating formulation offers an excellent mating surface for low pressure clip mounting applications.

FEATURES AND BENEFITS

• High breakdown voltage of 6,000 volts AC

• Thermal resistance of 0.50º C-in2/watt at 50 psi

• Unique coating formulation offers low mounting forces

• Unifying benefits of thermal & electrical performance for general-purpose applications

APPLICATIONS

• Switching mode power supplies

• Industrial equipment

• Motor controls

Tgard™ 300 SeriesThermally Conductive Insulators

Standard thickness: 9 mils (0.229 mm)

Configurations available:

• Sheet form, roll form and die-cut parts

• Single-side, pressure-sensitive adhesive on request

Standard options:

• Without adhesive (A0): 12 x 18" sheets, 12" x 65M, 12" x 30M roll or custom configuration

• With adhesive (A1): 11.75 x 18" sheets, 11.75" x 30M roll or custom configuration
