PRODUCT DESCRIPTION

Tpcm™ 780SP is a high performance, easy to use, screen printable or stencilable phase change thermal interface material proving a great alternative to grease. Developed

specifically to meet the high thermal conductivity and low thermal resistance requirements of today’s demanding processors. It contains a solvent to assist in processing, which allows for wetting of the surface. However, after the solvent evaporates, it will be dry to the touch; therefore, eliminating the mess associated with grease.

Tpcm™ 780SP is a silicone-free material that begins to further soften and flow at approximately 45ºC. This minimizes contact thermal resistance by filling the microscopic irregularities of the components it contacts. Designed with a specialty polymeric matrix which does not fully change phase, Tpcm™ 780SP drastically minimizes migration (pump out) over thermal greases and other phase change materials. Tpcm™ 780SP reliability has been demonstrated though exposure to 2000 hours of various aging tests resulting in proven dependability at an operating temperature of 125°C.

FEATURES AND BENEFITS

• Silicone-free for applications that are silicone sensitive

• No mess due to thixotropic characteristics which prevent flow outside of interface

• Very soft at room temperature, therefore less stress on board

• RoHS Compliant

• 94V0 UL Flammability Rating

APPLICATIONS

• Graphics Cards

• Notebooks

• Desktops

• Servers

• Memory Modules

• Automotive

• IGBTs

MARKETS

• Graphics Card

• Notebooks / Desktops

• Servers

• IGBTs

• Automotive

• Memory Modules

•  Game Consoles

AVAILABILITY

•  0.5 kg or 1.0 kg can for easy manual screen

printing and large volume automatic applications

STORAGE CONDITIONS

•  Store from 15˚C to 35˚C with a maximum humidity of 50% and with lid tightly closed. Do not store in a freezer or refrigerator at 5˚C or below

•  Shelf Life: 1 year from date of mix when stored at above conditions
