PRODUCT DESCRIPTION

Ttape™ 1000A Thermally Conductive Adhesive Tape is a stand-alone pressure sensitive adhesive featuring one of the lowest thermal resistances (at 50µm) available on the market, designed to facilitate the transfer of thermal energy from heat sources, such as IC chips, to heat sinks. Ttape™ 1000A offers a high degree of substrate conformability and adhesion needing only finger pressure to achieve excellent thermal performance eliminating the need for mechanical fasteners or clamping devices during assembly.

FEATURES & BENEFITS

• Best in Class Thermal Performance at 1.3°C-cm2/W at 100psi

• High Mechanical Strength

• RoHS Compliant

• Specialized Acrylic Formulation

• Easy to Use

• UL pending

AVAILABILITY

• 0.05mm thickness (Ttape™1050A)

• Ttape is supplied in standard

• 457mm x 75m rolls

• 228mm x 75m rolls

• 457mm x 457mm (18’x18”) sheets

• 228mm x 228mm (9”x9”) sheets

• Custom die cut parts (stand alone or on rolls)

• Easily automated

MARKETS

• Consumer Electronics

• Telecommunication Hardware

• Power Supplies

• Audio Amplifiers

• LED & Ballast Lighting

• Battery Charging

• Inverters

STORAGE CONDITIONS

• Store in original packaging at temperatures of 4°C - 29°C (40°F - 85 °F) and below 70% relative humidity.

• The product should not be frozen and should be kept dry, clean, and wellprotected.

• Shelf life is 1 year from the date of shipment
